Description:
Stand up to long days and complex mowing jobs with the redesigned 36-inch GrandStand stand-on mower. Combining the speed and comfort of a zero-turn riding mower with the ease and maneuverability of a walk mower, you'll knock out more jobs, faster, without the fatigue of a small walk-behind. From mowing to maintenance, this compact machine is built for easy, fast work.
Features:
- Compact for access to more yards, exceptional maneuverability, and easy storage and trailering.
- Mow more in less time without the fatigue that comes with operating a small walk-behind mower.
- Get the job done 3x faster than a 21-inch walk behind mower.**
- **Disclaimer: Ground coverage via wider cutting path and enhanced speed of 32" GrandStand Compact vs 21" Heavy Duty mower and will vary due to mowing conditions.
- Redesigned hood flips up for easy maintenance and cleaning.
- Trim close without damaging landscape structures or your chute.
- Lift and lock the rear cover into place to easily check and fill both engine oil and hydro fluid.
- Horizon360® Business Management Software. Work More Efficiently. Run More Profitably.
Specifications:
-
Product Type: Stand-On Mower
-
Product Use: Commercial
-
Engine Brand: Kawasaki
-
Engine Model: FS600V
-
Engine Horsepower: 18.5 hp*
-
Engine Displacement: 603 cc
-
Fuel Type: Gasoline
-
Fuel Capacity: 5 gal. / 18.9 L / 20 Qt.
-
Start Type: Electric
-
CARB Compliant: No
Performance
-
Forward Mowing/Transport Speed: Up to 7.5 mph / 12.0 kph
-
Blade Tip Speed: 18,500 ft/min / 5,638 m/min
-
Blade Design: 0.204 in. / 0.518 cm Thick Heat-Treated Steel
-
Cooling System: Air-Cooled
Cutting Deck
-
Deck Size: 36 in / 91 cm
-
Deck Design: Fabricated Weldment
-
Deck Material: 7-Gauge High-Strength Steel
-
Discharge Type: Side (Rubber Discharge Chute)
Drive System
-
Drive Type: Rear-Wheel Drive
-
Drive Tires: 21 in. x 8.5 in. - 10 in. (53.3 cm x 21.6 cm x 25.4 cm) Turf Tires
-
Drive System: Rear Wheel Drive
-
Clutch: Electromagnetic
-
Brake System: Lever Actuated Bar Brake (Parking Brake)
Chassis and Tires
-
Carrier Frame: Welded Heavy-Duty 1.5 in. x 3 in. Tube Steel
-
Caster Tires: 9 in. x 4.5 in. - 5 in. (22.8 cm x 11.4 cm - 12.5 cm) Smooth Semi-Pneumatic
-
Front Bumper: Bull-Nose
Comfort & Controls
-
Steering Controls: Twin Lever
-
Greasable Bearings: Yes
Air Filtration
-
Air Filter: Dual Element with Reinforced Primary Filter
Dimensions & Weight
-
Box Dimensions: 45.5 in. x 70 in. x 52 in. / 115.6 cm x 177.8 cm x 132.1 cm
-
Weight: 780 lbs / 354 kg
